Cleanrooms in Plasma & Pharma Manufacturing

1.   Cleanroom Grades (A, B, C, D)

🔹 Grade A – Critical Zone

The highest level of cleanliness, where the product is directly exposed during aseptic operations.
Examples:


• Aseptic filling of vials and syringes


• Ampoule sealing


• Sterile connections


• Open sterile equipment handling



Requirements:


• Unidirectional airflow (laminar flow) with HEPA filters


• Air velocity: ~0.36–0.54 m/s to sweep away particles


• Pressure differentials to protect from less clean areas



Particulate Limits (per m³):


• At rest: 3,520 particles ≥0.5µm; 0 particles ≥5µm


• In operation: 3,520 particles ≥0.5µm; 0 particles ≥5µm



Simple Term: 👉 The “surgical zone” of pharmaceutical manufacturing.

🔹 Grade B – Background for Grade A

The supporting clean area surrounding Grade A zones.
Examples:


• Background for filling machines


• Personnel gowning area before entering Grade A



Requirements:


• Works in tandem with Grade A


• HEPA-filtered air supply


• Maintained pressure differential vs. Grade C/D



Particulate Limits (per m³):


• At rest: 3,520 particles ≥0.5µm; 29 particles ≥5µm


• In operation: 352,000 particles ≥0.5µm; 2,900 particles ≥5µm



Simple Term: 👉 The “buffer zone” around aseptic filling.

🔹 Grade C – Clean Area

Used for less critical stages of sterile product manufacturing.
Examples:


• Preparation of solutions before sterile filtration


• Staging of equipment and materials



Requirements:


• HEPA-filtered air


• Not aseptic-critical, but controlled environment



Particulate Limits (per m³):


• At rest: 352,000 particles ≥0.5µm; 2,900 particles ≥5µm


• In operation: 3,520,000 particles ≥0.5µm; 29,000 particles ≥5µm



Simple Term: 👉 The “preparation area” before entry into aseptic zones.

🔹 Grade D – Controlled Area

The lowest cleanroom grade, used for non-critical stages.
Examples:


• Raw material preparation


• Bulk powder weighing (before sterilization)


• Washing/cleaning of equipment (before sterilization)



Requirements:


• General clean air supply (not as strict as A–C)



Particulate Limits (per m³):


• At rest: 3,520,000 particles ≥0.5µm; 29,000 particles ≥5µm


• In operation: Not defined (depends on process risk assessment)



Simple Term: 👉 A “controlled but not sterile” support area.

2. Types of Cleanrooms


• Conventional Cleanroom → Entire room is controlled with HVAC + HEPA.


• Laminar Airflow (LAF) Cleanroom → Controlled airflow in a single direction (used in Grade A).


• Modular Cleanroom → Flexible, pre-fabricated panels for fast setup & expansion.


• Hard wall Cleanroom → Permanent, rigid wall panels (common in pharma).


• Soft wall Cleanroom → Flexible curtain walls, used for temporary or less critical operations.


• Isolators / RABS → Closed barrier systems providing Grade A protection with minimal human intervention.



3. Key Equipment in Pharma/Plasma Cleanrooms
Air & Environmental Control:


• AHUs (Air Handling Units) – maintain temperature, humidity, pressure differentials.


• HEPA / ULPA Filters – for particle control.


• LAF Units (Laminar Airflow workbenches) – aseptic manipulations.


• Pass Boxes / Pass-Through Chambers – for material transfer.


• Airlocks (Personnel & Material) – contamination control.



Processing Equipment:


• Fractionation tanks – for plasma separation.


• Chromatography systems – for protein purification.


• Filtration units (sterile / ultrafiltration) – virus removal, purification.


• Aseptic filling & stoppering machines – vials, ampoules, syringes.


• Lyophilizes (Freeze-dryers) – for plasma proteins & injectables.



Utility & Support Systems:


• WFI (Water for Injection) Systems – critical clean utility.


• CIP/SIP Systems (Clean/Steam-in-place) – automated cleaning & sterilization.


• Compressed Air, Nitrogen, CO₂ Systems – process gases.


• Cold Rooms & Freezers – plasma storage.



Monitoring & Safety:


• Particle counters – for environmental monitoring.


• Bio-decontamination units (H₂O₂ fumigation) – sterilization.


• Differential pressure gauges – air pressure monitoring between zones.



4. Cleanroom Personnel & Flow Control


• Personnel Flow: Gowning sequence → Grade D → Grade C → Grade B → Grade A.


• Material Flow: Raw → staged in Grade D/C → sterilized transfer → final aseptic use in Grade A.


• Barriers: Airlocks, pass boxes, pressure cascades.
